The preferred solution for high intensity applications requiring non-marking resilient tires. Its design increases stability, reduces vibration and improves operator comfort for lower heat build-up and enhanced tire life. Its clean running and versatility make this tire the ideal solution for indoor operations and rental fleets.
Industries with the highest requirements of hygiene and cleanliness all rely on non-marking tires. Learn more about non-marking tire technology by Camso, which ensures a clean working environment, without sacrificing performance.
To find products that meet your vehicle needs, specify your requirements using the product selector.
| Tire size | Rim Size | Heel | Actual Tire Dimensions | Wearable Height | Load Capacity | |||
|---|---|---|---|---|---|---|---|---|
| Normal | Quick | Overall Diameter | Overall Width | Counterbalanced lift Trucks | ||||
| Up to 16 mph | ||||||||
| Load Wheel | Steering Wheel | |||||||
| in | in | in | lbs | lbs | ||||
| 5.00-8 | 3.00D-8 | True | True | 17.9 | 4.6 | 1.5 | 3120 | 2405 |
| 15x4 1/2-8 | 3.00D-8 | True | True | 14.9 | 4.4 | 1.1 | 2295 | 1765 |
| 16x6-8 | 4.33R-8 | True | True | 16.2 | 6 | 1.3 | 3295 | 2535 |
| 18x7-8 | 4.33R-8 | True | True | 17.8 | 6 | 1.7 | 4730 | 3640 |
| 140/55-9 | 4.00E-9 | True | 14.8 | 5.1 | 1.1 | 2580 | 1985 | |
| 6.00-9 | 4.00E-9 | True | True | 20.6 | 5.3 | 2.0 | 4155 | 3195 |
| 21x8-9 | 6.00E-9 | True | True | 20.4 | 7.2 | 1.9 | 6075 | 4675 |
| 180/60-10 | 5.00F-10 | True | 17.8 | 6.3 | 1.3 | 5315 | 4080 | |
| 200/50-10 | 6.50F-10 | True | True | 18 | 7.6 | 1.3 | 5445 | 4190 |
| 6.50-10 | 5.00F-10 | True | True | 22.4 | 6.2 | 2.2 | 5160 | 3970 |
| 23x9-10 | 6.50F-10 | True | True | 23 | 7.8 | 2.0 | 7595 | 5840 |
| 23x10-12 | 8.00G-12 | True | True | 23.1 | 9.2 | 1.8 | 8310 | 6395 |
| 23x12-12 | 10.00G-12 | True | True | 23 | 11.1 | 1.7 | 9890 | 7605 |
| 27x10-12 | 8.00G-12 | True | True | 26.8 | 9.5 | 2.5 | 8600 | 6615 |
| 7.00-12 | 5.00S-12 | True | True | 25.7 | 6.5 | 2.4 | 6435 | 4940 |
| 28x9-15 | 7.00-15 | True | True | 27.1 | 8.4 | 2.1 | 8600 | 6615 |
| 355/45-15 | 9.75-15 | True | True | 27.2 | 11.3 | 2.1 | 12545 | 9645 |
| 355/50-15 | 9.75-15 | True | True | 28 | 11.6 | 2.0 | 12545 | 9645 |
| 355/65-15 | 9.75-15 | True | True | 32.2 | 12.3 | 2.9 | 17195 | 13230 |
| 250-15 | 7.00-15 | True | True | 28.3 | 8.7 | 2.4 | 10460 | 8045 |
| 250-15 | 7.50-15 | True | True | 28.3 | 8.9 | 2.4 | 10460 | 8045 |
| 300-15 | 8.00-15 | True | True | 32.1 | 10.1 | 3.0 | 12895 | 9920 |
| 7.00-15 | 5.50-15 | True | True | 28.7 | 7 | 2.3 | 7815 | 6010 |
| 7.00-15 | 6.00-15 | True | 28.7 | 7 | 2.3 | 7815 | 6010 | |
| 7.50-15 | 5.50-15 | True | 29.6 | 7.8 | 2.4 | 8600 | 6615 | |
| 7.50-15 | 6.00-15 | True | 29.6 | 7.8 | 2.4 | 8600 | 6615 | |
| 7.50-15 | 6.50-15 | True | True | 29.6 | 7.8 | 2.4 | 8600 | 6615 |
| 8.25-15 | 5.50-15 | True | True | 32 | 8.3 | 2.8 | 10175 | 7825 |
| 8.25-15 | 6.50-15 | True | True | 32 | 8.3 | 2.8 | 10470 | 8045 |
| 400/60-15 | 11.00 - 15 | True | True | 32.3 | 12.7 | 2.7 | 19775 | 15210 |
| 7.50-16 | 6.00-16 | True | 31.5 | 8.1 | 2.6 | 8740 | 6725 | |
| 355/50-20 | 10.00-20 | True | True | 32.7 | 12.3 | 1.9 | 19775 | 15210 |
| 9.00-20 | 7.00-20 | True | 39.3 | 9 | 3.0 | 11905 | 9920 | |
| 10.00-20 | 7.00-20 | True | 40.7 | 10 | 3.2 | 13230 | 11025 | |
| 10.00-20 | 7.50-20 | True | True | 40.7 | 10 | 3.2 | 13230 | 11025 |
| 10.00-20 | 8.00-20 | True | 40.7 | 10 | 3.2 | 13230 | 11025 | |
| 12.00-20 | 8.00-20 | True | 42.9 | 11.1 | 3.4 | 16665 | 13890 | |
| 12.00-20 | 8.50-20 | True | 42.9 | 11.1 | 3.4 | 16665 | 13890 | |
| 12.00-20 | 10.00-20 | True | 42.8 | 13.1 | 3.2 | 17195 | 14330 | |
| 12.00-20 EW | 10.00-20 | True | 42.8 | 13.5 | 3.6 | 17195 | 14330 | |
| 465/55-20 | 16.00-20 | True | 40.2 | 18.2 | 3.0 | 23810 | 19840 | |
| 12.00-24 | 8.50-24 | True | 46.7 | 11.1 | 3.9 | 17725 | 14770 | |
