Solideal ED Plus NM

Name: Camso
Price range: $

Durable, performing and comfortable non-marking tire

Its unique tread design delivers a smooth, comfortable ride with great overall tire life. In addition to providing superior carcass strength and sidewall protection, it’s also the ideal non-marking solution for indoor operations and for electrical and rental fleets.

COMFORT

90%

ENERGY SAVING

90%

PONCTURE RESISTANCE

30%

TIRE LIFE

40%

Find a dealer

Product sheet A4 Datasheet Metric Datasheet Imperial

Deep tread

Improves tire life and provides better traction

Unique tread design with flat profile

Increases stability, while reducing vibrations for better comfort

Thick sidewall

Protects against side impacts causing flat tires
Two times more rubber than standard tires

Heavy-duty carcass

Maximizes tread puncture-resistance to prevent flat tires

Non-marking natural rubber compound

Prevents visible marks on the floor,ensuring a clean working environment
Reduces chunking and cutting

WHAT ARE THE BENEFITS OF 100% NATURAL RUBBER NON-MARKING TIRES?

Industries with the highest requirements of hygiene and cleanliness all rely on non-marking tires. Learn more about non-marking tire technology by Camso, which ensures a clean working environment, without sacrificing performance.

Get Cheatsheet

Specifications for all product size(s)

To find products that meet your vehicle needs, specify your requirements using the product selector.

Tire size	PR	Tube & Valve	Flap	Rim Size		Actual Tire Dimensions				Inflation Pressure	Load Index	Speed Symbol	Load Capacity
				Recommended	Alternative	Overall Diameter	Overall Width	Original Tread Depth	Static Loaded Radius				Counterbalanced lift Trucks
													Up to 16 mph		Up to 22 mph
													Load Wheel	Steering Wheel	Load Wheel	Steering Wheel
						in	in	in	in	psi			lbs	lbs	lbs	lbs
4.00-8	10	JS2	90-8	3.25I	3.00D	422	115	12	196	10.00	97	A5	950	730	915	675
4.00-8	10	JS2	90-8	3.25I	3.00D	16.6	4.5	0.5	7.7	145	97	A5	2095	1610	2015	1490
5.00-8	8	JS2	90-8	3.00D	3.25I/3.75I	18.4	5.2	0.5	8.3	120	106	A5	2725	2095	2625	1940
5.00-8	8	JS2	90-8	3.00D	3.25I/3.75I	467	132	14	210	8.25	106	A5	1235	950	1190	880
5.00-8	10	JS2	90-8	3.00D	3.25I/3.75I	461	128	15	213	10.00	111	A5	1415	1090	1365	1010
5.00-8	10	JS2	90-8	3.00D	3.25I/3.75I	18.1	5	0.6	8.4	145	111	A5	3120	2405	3010	2225
16x6-8	14	V3-02-5	130-8	4.33R	-	16.5	5.8	0.5	7.5	140	111	A5	3120	2405	3010	2225
16x6-8	14	V3-02-5	130-8	4.33R	-	420	147	13	191	9.50	111	A5	1415	1090	1365	1010
18x7-8	14	V3-02-5	130-8	4.33R	5.00F	460	155	9	208	9.00	121	A5	1885	1450	1815	1340
18x7-8	14	V3-02-5	130-8	4.33R	5.00F	18.1	6.1	0.4	8.2	130	121	A5	4155	3195	4000	2955
18x7-8	16	V3-02-5	130-8	4.33R	5.00F	18.1	6.2	0.6	8.1	145	125	A5	4730	3640	4555	3360
18x7-8	16	V3-02-5	130-8	4.33R	5.00F	459	157	16	207	10.00	125	A5	2145	1650	2065	1525
6.00-9	10	JS2	125-9	4.00E	-	534	165	11	245	8.50	118	A5	1715	1320	1650	1220
6.00-9	10	JS2	125-9	4.00E	-	21	6.5	0.4	9.6	125	118	A5	3780	2910	3640	2690
6.00-9	12	JS2	125-9	4.00E	-	21.1	6.3	0.6	9.7	145	121	A5	4155	3195	4000	2955
6.00-9	12	JS2	125-9	4.00E	-	536	160	15	247	10.00	121	A5	1885	1450	1815	1340
21x8-9	14	JS2	180-9	6.00E	7.00E	531	194	21	240	9.00	131	A5	2535	1950	2440	1805
21x8-9	14	JS2	180-9	6.00E	7.00E	20.9	7.6	0.8	9.4	130	131	A5	5590	4300	5380	3980
6.50-10	10	JS2	140-10	5.00F	5.50F	23.2	7	0.4	10.7	110	122	A5	4300	3305	4135	3065
6.50-10	10	JS2	140-10	5.00F	5.50F	590	179	10	271	7.75	122	A5	1950	1500	1875	1390
6.50-10	12	JS2	140-10	5.00F	5.50F	588	185	15	265	9.00	125	A5	2145	1650	2065	1525
6.50-10	12	JS2	140-10	5.00F	5.50F	23.1	7.3	0.6	10.4	130	125	A5	4730	3640	4555	3360
6.50-10	14	JS2	140-10	5.00F	5.50F	23.1	7.1	0.4	10.7	145	128	A5	5160	3970	4960	3670
6.50-10	14	JS2	140-10	5.00F	5.50F	588	181	10	271	10.00	128	A5	2340	1800	2250	1665
7.50-10	16	JS2	140-10	5.50F	5.00F	632	207	10	291	10.00	138	A5	3070	2360	2950	2185
7.50-10	16	JS2	140-10	5.50F	5.00F	24.9	8.1	0.4	11.5	145	138	A5	6770	5205	6505	4815
23x9-10	18	JS2	180-10	6.50F	-	22.8	9.1	0.8	10.4	130	139	A5	6965	5355	6700	4960
23x9-10	18	JS2	180-10	6.50F	-	580	232	20	263	9.00	139	A5	3160	2430	3040	2250
23x10-12	16	JS2	210-12	8.00G	-	591	239	14	270	8.00	139	A5	3160	2430	3040	2250
23x10-12	16	JS2	210-12	8.00G	-	23.3	9.4	0.6	10.6	115	139	A5	6965	5355	6700	4960
27x10-12	20	V3-02-5	210-12	8.00G	-	26.8	10	0.6	12.0	145	152	A5	10175	7825	9790	7240
27x10-12	20	V3-02-5	210-12	8.00G	-	680	254	14	304	10.00	152	A5	4615	3550	4440	3285
7.00-12	12	TR75A	135-12	5.00S	-	675	194	16	305	8.50	133	A5	2680	2060	2575	1905
7.00-12	12	TR75A	135-12	5.00S	-	26.6	7.6	0.6	12.0	125	133	A5	5910	4540	5675	4200
7.00-12	14	TR75A	135-12	5.00S	-	26.7	7.6	0.5	12.3	130	134	A5	6075	4675	5840	4320
7.00-12	14	TR75A	135-12	5.00S	-	677	194	12	312	9.00	134	A5	2755	2120	2650	1960
7.00-12	16	TR75A	135-12	5.00S	-	669	191	12	309	10.00	136	A5	2910	2240	2800	2070
7.00-12	16	TR75A	135-12	5.00S	-	26.3	7.5	0.5	12.2	145	136	A5	6415	4940	6175	4565
23x5	10	JS2	130-13	3.75P	-	25	5.9	0.4	11.7	110	122	A5	4300	3305	4135	3065
23x5	10	JS2	130-13	3.75P	-	635	149	10	298	7.75	122	A5	1950	1500	1875	1390
355/45-15	24	V3-02-10	260-15	9.75	-	703	292	11	321	10.00	159	A5	5690	4375	5470	4045
355/45-15	24	V3-02-10	260-15	9.75	-	27.7	11.5	0.4	12.6	145	159	A5	12545	9645	12060	8920
355/65-15	24	TR78A	260-15	9.75	-	33.4	12.8	0.9	15.3	145	170	A5	17195	13230	16535	12235
355/65-15	24	TR78A	260-15	9.75	-	848	324	23	388	10.00	170	A5	7800	6000	7500	5550
28x9-15	14	V3-02-08	180-15 HD	7.00	-	710	226	14	329	10.00	146	A5	3900	3000	3750	2775
28x9-15	14	V3-02-08	180-15 HD	7.00	-	28	8.9	0.5	13.0	145	146	A5	8600	6615	8265	6120
28x9-15	16	V3-02-08	180-15 HD	7.00	-	27.8	8.8	0.7	12.8	145	146	A5	8600	6615	8265	6120
28x9-15	16	V3-02-08	180-15 HD	7.00	-	707	223	19	326	10.00	146	A5	3900	3000	3750	2775
250-15	16	TR77A	180-15 HD	7.50	7.00	734	238	13	338	8.25	150	A5	4355	3350	4190	3100
250-15	16	TR77A	180-15 HD	7.50	7.00	28.9	9.4	0.5	13.3	120	150	A5	9600	7385	9235	6835
250-15	18	TR77A	180-15 HD	7.50	7.00	28.9	9.1	0.8	13.2	140	153	A5	10460	8045	10065	7440
250-15	18	TR77A	180-15 HD	7.50	7.00	735	231	21	336	9.50	153	A5	4745	3650	4565	3375
300-15	18	TR78A	180-15 HD	8.00	-	833	287	19	377	7.50	160	A5	5850	4500	5625	4165
300-15	18	TR78A	180-15 HD	8.00	-	32.8	11.3	0.7	14.8	110	160	A5	12895	9920	12400	9180
300-15	22	TR78A	180-15 HD	8.00	-	32.8	11.3	0.7	14.8	145	165	A5	14760	11355	14200	10505
300-15	22	TR78A	180-15 HD	8.00	-	833	287	18	377	10.00	165	A5	6695	5150	6440	4765
7.00-15	14	TR75A	180-15	5.50	5.00	762	202	17	344	9.00	140	A5	3350	2575	3220	2380
7.00-15	14	TR75A	180-15	5.50	5.00	30	8	0.7	13.5	130	140	A5	7385	5675	7100	5245
7.50-15	14	TR75A	180-15	6.00	5.50/6.50	30.9	8.3	0.8	14.1	135	144	A5	8025	6175	7715	5710
7.50-15	14	TR75A	180-15	6.00	5.50/6.50	784	212	20	357	9.25	144	A5	3640	2800	3500	2590
8.25-15	14	TR77A	180-15	6.50	6.00/7.00	846	251	13	390	8.00	149	A5	4225	3250	4065	3005
8.25-15	14	TR77A	180-15	6.50	6.00/7.00	33.3	9.9	0.5	15.4	115	149	A5	9315	7165	8960	6625
8.25-15	16	TR77A	180-15	6.50	6.00/7.00	33.3	9.9	0.7	15.0	135	152	A5	10175	7825	9790	7240
8.25-15	16	TR77A	180-15	6.50	6.00/7.00	845	252	19	380	9.25	152	A5	4615	3550	4440	3285
7.50-16	12	TR75A	180-16	6.0	5.0/5.50	810	209	12	373	8.00	144	A5	3640	2800	3500	2590
7.50-16	12	TR75A	180-16	6.0	5.0/5.50	31.9	8.2	0.5	14.7	115	144	A5	8025	6175	7715	5710
9.00-20	14	V3-02-14	200-20	7.00	6.50/7.50	41.2	11.3	0.9	18.7	130	160	A5	12895	9920	12400	9180
9.00-20	14	V3-02-14	200-20	7.00	6.50/7.50	1046	286	23	476	9.00	160	A5	5850	4500	5625	4165
10.00-20	16	V3-02-14	200-20	7.50	7.00/8.00	1065	286	13	494	9.00	164	A5	6500	5000	6250	4625
10.00-20	16	V3-02-14	200-20	7.50	7.00/8.00	41.9	11.3	0.5	19.4	130	164	A5	14330	11025	13780	10195
10.00-20	20	V3-02-14	200-20	7.50	7.00/8.00	42	11.2	0.5	19.4	145	166	A5	15190	11685	14605	10815
10.00-20	20	V3-02-14	200-20	7.50	7.00/8.00	1067	284	13	494	10.00	166	A5	6890	5300	6625	4905
11.00-20	16	V3-02-14	200-20	8.00	7.50/8.50	1087	301	13	505	9.00	167	A5	7085	5450	6815	5040
11.00-20	16	V3-02-14	200-20	8.00	7.50/8.50	42.8	11.9	0.5	19.9	130	167	A5	15620	12015	15025	11110
12.00-20	20	V3-02-14	200-20	8.50	8.00/9.00	44.8	12.8	0.7	20.7	145	176	A5	20350	15655	19565	14485
12.00-20	20	V3-02-14	200-20	8.50	8.00/9.00	1138	326	18	526	10.00	176	A5	9230	7100	8875	6570
12.00-20	28	V3-02-14	200-20	8.50	8.00/9.00	1142	324	18	528	10.00	176	A5	9230	7100	8875	6570
12.00-20	28	V3-02-14	200-20	8.50	8.00/9.00	45	12.8	0.7	20.8	145	176	A5	20350	15655	19565	14485
