Specifications for all product size(s)

To find products that meet your vehicle needs, specify your requirements using the product selector.

Tire size Actual Tire Dimensions Load Capacity
Overall Diameter Overall Width Counterbalanced lift Trucks
Up to 6 mph Up to 10 mph Up to 16 mph
Load Wheel Steering Wheel Load Wheel Steering Wheel Load Wheel Steering Wheel
in in lbs lbs lbs lbs lbs lbs
10 x 5 x 6 1/2105223818411995167516201334
14 x 4 1/2 x 8144.5256821052293192918631532
16 x 5 x 10 1/215.95331827342965249124141973
16 x 6 x 10 1/215.96420034503748315330532502
15 x 5 x 11 1/414.95306425242734230422271830
16 1/4 x 5 x 11 1/416.25336227562998252424361995
16 1/4 x 6 x 11 1/416.26422234613770316430642513
18 x 6 x 12 1/817.96460837814112345033402745
18 x 7 x 12 1/817.97563346305026422240903351
18 x 8 x 12 1/817.98661454345908496048063935
21 x 7 x 1520.97632752035655475145973770
21 x 8 x 1520.98744161186647557854014431
22 x 9 x 1621.89891873307970669164824718
